Downloads - Universal Pulse Generators

Datasheets RUP3

RUP3-3A

Umax = -3kV | Imax = (40)A |  Paverage = 0.03kW

Size: 80 kB

RUP3-7bip

For capacitive loads, allows to switch between a negative voltage of -7.5kV....0V and a positive voltage of 0...+7.5kV
Umax = ±7.5kV | Imax = 5A |  Paverage = 2*0.5kW

Size: 45 kB

RUP3-6ax2 (german)

Special version with two outputs which can be shifted in phase.
Umax = 2x6kV | Imax = 5A |  Paverage = 0.7kW

Size: 27 kB

RUP3-5ion (german)

Special version for an ion source; two outputs which are synchronously switched.
Umax = -+5 - 0.1kV | Imax = 6A |  Paverage = 10kW
Umax = -+0.2 - (-0.8)kV

Size: 67 kB

RUP3-2A (german)

Umax = -2.2kV | Imax = (40)A |  Paverage = 0.01kW

Size: 40 kB

RUP3-2/6B

Additionally up to -200V bias.
Umax = -2kV | Imax = 10A |  Paverage = 0.2kW

Size: 69 kB

RUP3-5A

Umax = +5kV | Imax = 1A |  Paverage = 0.1kW

Size: 71 kB

RUP3-5aN (german)

Especially for ion sources, in the state "off" there is a slightly positive voltage (current limited) at the output.
Umax = -5kV | Imax = 1A |  Paverage = 0.1kW

Size: 72 kB

RUP3-5AS

Output resistor is exchangeable, therefore rise and fall time can be adjusted.
Umax = +5kV | Imax = 10A |  Paverage = 0.024kW

Size: 40 kB

RUP3-5A RS232 (german)

RUP can be controlled via RS232 interface.
Umax = +5kV | Imax = 1A |  Paverage = 0.1kW

Size: 78 kB

RUP3-5/1A (german)

Umax = -5kV | Imax = 2A |  Paverage = 0.9kW

Size: 71 kB

RUP3-9Aoem

OEM-version
Umax = +9kV | Imax = 12A |  Paverage = 0.012kW

Size: 38 kB

RUP3-10Aoem

OEM version, output capacitively coupled, potential free.
Umax = +10kV | Imax = 5A |  Paverage = 0.003kW

Size: 26 kB

RUP3-10a/001

Umax = +10kV | Imax = 3A |  Paverage = 0.015kW

Size: 38 kB

RUP3-10B

Special version with AC bias up to ±200V
Umax = +10kV +(±200V bias) | Imax = 10A |  Paverage = 0.9kW

Size: 71 kB

RUP3-15/50A (german)

Umax = -15kV | Imax = 5A |  Paverage = 0.75kW

Size: 59 kB

RUP3-25A

Umax = +25kV | Imax = 1A |  Paverage = 0.025kW

Size: 23 kB

Datasheets RUP6

RUP6-3x2

Special version with two outputs, designed for high voltage magnetron sputtering.
Umax = -3kV | Imax = 2*40A |  Paverage = 1.2kW
German

Size: 35 kB

RUP6-10CL

Modified topology for voltage testing of inductive as well as capacitive loads
Umax = -10kV | Imax = 200A |  Paverage = 2.5kW

Size: 61 kB

RUP6-1L

Universal device for small average power, 5HE desktop housing.
Umax = -1kV | Imax = 100A |  Paverage = 0.1kW

Size: 45 kB

RUP6-12CL (V2)

Optimized for capacitive loads, rise time can be varied in a broad range.
Umax = -12kV | Imax = 100A | Paverage = 2.5kW

Size: 302 kB

RUP6-3iws

Designed for high power arc coating machines.
Umax = -3kV | Imax = 200A |  Paverage = 2.5kW

Size: 138 kB

RUP6-6d

Additional lower voltage, high current mode (-1kV, 2.5A average), and -200V, 1A bias supply.
Umax = -6kV | Imax = 50A |  Paverage = 2.5kW

Size: 88 kB

RUP6-12c

Special version for 3*480V supply voltage and a high voltage relais in the output.
Umax = -12kV | Imax = 120A |  Paverage = 6kW

Size: 61 kB

RUP6-22

Umax = -22kV | Imax = 50A |  Paverage = 2.5kW

Also availible with -200V bias as RUP6-22B

Size: 72 kB

RUP6-10L (german)

Umax = -6kV | Imax = 60A |  Paverage = 2.5kW

Size: 73 kB

RUP6-35L (german)

Umax = -35kV | Imax = 60A |  Paverage = 2.5kW

Size: 52 kB

RUP6-17CL

Umax = -17kV | Imax = 200A |  Paverage = 12kW

Size: 54 kB

Datasheets RUP6 bipolar

RUP6-25 bipolar

In contrary to standard RUP6 there are full bridges instead of half bridges on the pulse modules. Therefore both polarities are possible, even arbitrary pulses with alternating polarity.
All bipolar RUP6 have adjustable ramp times and were designed for insulation testing applications.
Umax = ±25kV | Imax = 50A |  Paverage = 2kW



Size: 42 kB

RUP6-18 bipolar

Umax = ±18kV | Imax = 50A |  Paverage = 2kW

Size: 316 kB

Datasheets RUP7

RUP7-2 (german)

RUP7 with 2 operating modes for plasma coating applications

Umax = 1kV / 2kV | Imax = 200A / 400A |  Paverage = 15kW

Size: 75 kB

RUP7MV (german)

Current is controlled by analog control signal, nearly arbitrary waveforms can be generated.
Umax = 400V | Imax = 2500A |  Paverage = 3.2kW

Size: 419 kB

RUP7MV5 (german)

Peak current 5000A.Enhanced version of RUP7MV
Umax = 400V | Imax = 5000A |  Paverage = 3.2kW

Size: 97 kB

Datasheets RUP8

RUP8-90

RUP8 with 90kV

Size: 146 kB

Datasheets RUP with tube technology

Size: 85 kB
